Electronic universal testing machine with video extensometer configuration

Electronic universal testing machine
The WDW-100M double column portal microcomputer controlled electronic universal testing machine can complete various material mechanics tests such as tension, compression, bending, tearing, peeling, and shearing. The equipment is equipped with the LVE series video extensometer, which belongs to a non-contact high-precision real-time measurement system. It is equipped with an independent digital camera and real-time image processing algorithm. During the test process, the specimen imag...



    The WDW-100M double column door microcomputer controlled electronic universal testing machine has an accuracy level of 0.5. The equipment has a stable structure and precise transmission, and can complete various material mechanics tests such as tension, compression, bending, tearing, peeling, and shearing. The equipment can be equipped with LVE series video extensometer, which belongs to non-contact high-precision real-time measurement system. It is equipped with independent digital camera and real-time image processing algorithm. During the test process, the specimen images are continuously collected, and strain and displacement data are dynamically and real-time collected by analyzing the changes in image features; The equipment can communicate with the control system of the testing machine, synchronously generate stress-strain curves and various mechanical performance parameters, and can accurately collect strain data for easily scratched and high elongation specimens such as rubber, plastic film, soft plastic, metal foil, carbon fiber composite materials, etc. Widely used in material laboratories, research institutes, new material enterprises, and quality inspection institutions of major universities.

Characteristics of video extensometer

    Non contact measurement: avoid the additional influence of contact methods such as strain gauges and clamping extensometers on measurement

    Full process tracking: No need to stop the entire process, sample breakage will not damage the measuring device, and the entire process can be tracked

    Diversified scenarios: In addition to general scenarios, it can also adapt to special experiments such as large deformation, small deformation, high and low temperature, etc

    Wide material adaptability: Strong adaptability to materials, able to test specimens of different sizes and materials

    Sub-pixel level measurement accuracy: Based on image processing correlation method, the calculation accuracy reaches sub-pixel level

    Large strain range: Measurable strain range from 0.002% to over 1000%

    Custom gauge length: Customize gauge length size, set arbitrarily within a few hundred millimeters

    Multi directional simultaneous measurement: capable of simultaneously calculating longitudinal and transverse strains

    Multi point co measurement: capable of measuring strain at multiple points, suitable for multi specimen testing, multi section testing, etc



ModelWDW-10(20)MWDW-(50)100MWDW-200(300)M
Max. test force(kN)10(20)50(100)200(300)
Testing machine accuracy0.5 class0.5 class0.5 class
Relative error of test force indicationWithin ±0.5%Within ±0.5% Within ±0.5%
Testing force measurement range1%~100%FS1%~100%FS1%~100%FS
Deforamtion(extensometer)measurement range1%~100%FS1%~100%FS1%~100%FS
Relative error of deformationWithin ±0.5% Within ±0.5% Within ±0.5%
Range of force control rate0.005~0.5FS/s
Accuracy of force control rateWhen the rate is less than 0.05%FS/s, it is within ±1% of the set value; when the rate is greater than or equal to 0.05%FS/s, it is within ±0.5% of the set value
Range of strain control rate0.005~0.5FS/s0.005~0.5FS/s0.005~0.5FS/s
Accuracy of strain control rateWhen the rate is less than 0.05%FS/s, it is within ±1% of the set value

When the rate is greater than or equal to 0.05%FS/s, it is within ±0.5% of the

 set value.

Accuracy of displacement control rateWithin ±0.5% of the set value
Crosshead movement range(mm)800900900
Crosshead moving speed(mm/min)0.001~5000.001~5000.001~200
Width of test space(mm)370475500
Max. tensile test space(mm)800700600
Max. Compression test space(mm)110011001000
Round grip size range(mm)Φ4~Φ20Φ4~Φ20Φ4~Φ26
Flat grip thickness range(mm)0~200~200-26
Compression platen size(mm)Φ100Φ100Φ120
Frame dimension (length×width×height mm)686×525×1810845×660×20601000×760×2638
Total power(kW)0.751.52.5
Weight(kg)3007001600
Power220V/50Hz±10%220V/50Hz±10%220V/50Hz±10%
