WDW- E Computer Control Electronic Universal Testing Machine/tensile testing machine

Electronic universal testing machine
Computer Control Electronic Universal Testing MachineWDW-E series Computer control electronic universal testing machine is a high-precision, multi-purpose material testing machine for testing the mechanical properties of various metal materials, non-metal materials, composite materials, polymer materials and other materials. The servo motor drives the precision ball screw to rotate thr...

Computer Control Electronic Universal Testing Machine

WDW-E series Computer control electronic universal testing machine is a high-precision, multi-purpose material testing machine for testing the mechanical properties of various metal materials, non-metal materials, composite materials, polymer materials and other materials. The servo motor drives the precision ball screw to rotate through the deceleration system, and drives the loading beam to move up and down to complete the tensile, compression, bending, shearing, tearing, peeling, puncturing, bursting and other tests of the sample or component. Both the stretching space and the compression space can be adjusted automatically by the rotation of the lead screw and driving the middle beam to move up and down. The precision closed-loop control system composed of controller, servo motor, load sensor, displacement sensor, extensometer and computer can automatically and accurately control the test process and automatically measure test parameters such as test force, displacement and deformation. The testing machine can realize tests such as constant rate test force, constant rate deformation, and constant rate displacement, and can realize three-stage control of force, deformation and displacement in one test, and the control can be smoothly switched The test parameters are collected by computer and processed by software, which can automatically control the test process and automatically obtain the test results. The test curve and test results are displayed on the computer screen in real time, and the test report and test curve can be printed

No.

Specification

WDW-100E

WDW-200E

1

Max. Test force(kN)

100

200

2

Testing Machine accuracy

0.5 glass

0.5 glass

3

Relative error of test force indication

Within ±0.5%

Within ±0.5%

4

Test force measurement range

0.4%-100%FS

0.4%-100%FS

5

Deformation (Extensometer) Measuring Range

1%--100%FS

1%--100%FS

6

Deformation indication relative error

Within±0.5%

Within ±0.5%

7

Strain Control Rate Range

0.005-0.5FS/S

0.005-0.5FS/S

8

Crosshead moving stroke (mm)

900

900

9

Crosshead moving speed(mm/min)

0.001~500

0.001~500

10

Effective test width(mm)

600

600

11

Maximum tensile space(mm)

600

600

12

Maximum compression space(mm)

600

600

13

Round Grips(mm)

Φ4~Φ20

Φ4~Φ20

14

Compression platen size(mm)

Ø100

Ø100

15

Frame dimension(length×witdth×height mm)

860*720*1978

1110×770×2558mm

16

Total power(kW)

1000W;

3500W;

17

Weight(kg)

1000

1600

18

Power

380V/50Hz±10%

380V/50Hz±10%
