Product Overview:
The universal tensile testing machine for wood-based panels is used to test and analyze various mechanical performance indicators of various wood-based panels such as plywood, particleboard, medium density fiberboard, and veneer wood-based panels. It is widely used in the deep processing industry of wood and wood-based panel manufacturing enterprises
The universal tensile testing machine for wood-based panels can automatically obtain conventional test data such as internal bond strength, static bending strength, modulus of elasticity in bending, surface bond strength, glue bond strength, and screw holding strength according to the national standard GB/T17657-1999 "Test Methods for Physical and Chemical Properties of Wood-Based Panels and Surface Decorated Wood-Based Panels".
Main technical indicators:
1. Maximum test force: 10KN
2. Operation mode: Microcomputer control, Windows operation
3. Measurement range: 2% to 100% of the maximum test force
4. Accuracy level of testing machine: Level 1
5. Accuracy of test force: better than ±1% of the indicated value
6. Beam displacement measurement: resolution of 0.01mm
7. Deformation accuracy: better than ±1%
8. Speed range: 0.01-500mm/min
9. Test space: 600mm
10. Main machine form: Portal frame structure
11. Host dimensions: 660*420*1700
12. Weight: approximately 500Kg
13. Operating Environment: Room temperature to 45℃, humidity 20% to 80%
